Logs, audit, doctor, pairing & skins pages

This page covers the dashboard’s inspection and operations surfaces — the screens you reach for when something looks off or when you want to brand and pair a deployment. The Inspection section holds the live Logs stream, the tamper-evident Audit trail, and the on-demand Doctor diagnostics. The Operations section holds Device Pairing and UI Skins. Two cross-page systems also live here: the approval toaster (fed by an app-wide agent-events SSE stream) and the theme / skin runtime with its language switcher.

Use Logs to watch the daemon in real time, Audit to prove nothing has been tampered with, Doctor to triage a misconfiguration, Pairing to authorize a new browser or phone, and Skins to re-theme the dashboard. Everything here lives behind the dashboard’s bearer-token auth — see Run the dashboard to pair a browser first.

Logs page (/logs)

The Logs page is a live, real-time event stream from the daemon over Server-Sent Events. As the agent runs, coloured event cards appear at the bottom and auto-scroll into view. The buffer is capped at the most recent 500 entries — older cards are dropped as new ones arrive.

It subscribes to one SSE endpoint:

GET /api/daemon/logs
Authorization: Bearer rk_<token>
Accept: text/event-stream

This is a live tail: historical logs are not replayed when you connect, so you only see events that occur after the page opens. The underlying SSEClient reconnects automatically if the stream drops.

Event types

Each event renders as a colour-coded card by type. The page recognises:

Event type	Meaning
error	An error emitted by the runtime
warn / warning	A warning
tool_call / tool_call_start / tool_result	Agent tool activity
llm_request	An outbound model request
agent_start / agent_end	Agent turn boundaries
message / chat	Chat traffic
log	Generic log line
log_unavailable	The gateway could not read its log file

A log_unavailable event means the daemon is up but cannot tail its own log file — check file permissions and the log path rather than assuming the agent is idle.

Controls

• Pause / Resume — freeze the stream so you can read a card without it scrolling away. New events keep arriving in the background; resume to catch up.
• Auto-scroll — the panel follows the newest entry by default. Clicking anywhere inside the panel disables auto-scroll so you can inspect older cards; it re-engages when you scroll back to the bottom.
• Type filters — toggle the event-type chips to hide or show whole categories (for example, mute tool_call noise to focus on error and warn).

Note

The 500-entry cap is a rolling client-side buffer, not the full history. For a persisted, queryable record of security-relevant actions, use the Audit trail instead — and for runtime traces with model output, use revka doctor traces (see revka doctor, status & self-test).

Audit trail page (/audit)

The Audit page is the viewer for Revka’s tamper-evident Merkle hash-chain audit log. Every security-relevant event is appended to an append-only JSONL log where each entry’s entry_hash is SHA-256(prev_hash || canonical_content) and carries a monotonically increasing sequence. Modifying or deleting any entry breaks every hash after it — which is exactly what the chain verifier detects.

It is backed by two endpoints:

Action	Method + path	Auth
List events	GET /api/audit?limit=100&event_type=<type>	Bearer
Verify chain integrity	GET /api/audit/verify	Bearer

GET /api/audit accepts limit (default 50, max 500), an optional event_type filter, and an optional since RFC 3339 timestamp. Each event has this shape:

{
  "timestamp": "2026-06-18T10:00:00Z",
  "event_id": "<uuid>",
  "event_type": "command_execution",
  "actor": { "channel": "telegram", "user_id": "123", "username": "@alice" },
  "action": { "command": "ls -la", "risk_level": "low", "approved": false, "allowed": true },
  "result": { "success": true, "exit_code": 0, "duration_ms": 15 },
  "security": { "policy_violation": false, "rate_limit_remaining": 19, "sandbox_backend": "firejail" },
  "sequence": 42,
  "prev_hash": "<64 hex>",
  "entry_hash": "<64 hex>",
  "signature": "<64 hex>"
}

Event types

Filter the stream with the event-type dropdown. The supported types are:

command_execution, file_access, config_change, auth_success, auth_failure, policy_violation, and security_event.

Any event whose security.policy_violation is true is flagged with a policy-violation badge so blocked or risky actions stand out at a glance.

Verify the chain

Click Verify Chain to run the integrity check. The result renders inline with a shield icon: green when verified, red when invalid, alongside the total entry_count and an error message if the chain is broken.

GET /api/audit/verify
Authorization: Bearer rk_<token>

{ "verified": true, "entry_count": 1284 }

The same check powers the Risk Rail audit badge on the Dashboard overview, which re-polls /api/audit/verify every 60 seconds and on window focus. A failed verification means the on-disk log has been altered — the most security-significant alarm the dashboard can raise.

Caution

The audit log can be turned off with enabled = false under [security.audit] in config.toml. When disabled the API returns empty events (not an error) and the page shows a disabled state — so a blank Audit page may simply mean auditing is off, not that nothing happened. Log rotation (max_size_mb) resets the chain to genesis; rotated archives remain independently verifiable. Optional HMAC signing adds a signature to each entry when sign_events = true and the REVKA_AUDIT_SIGNING_KEY env var (32 bytes / 64 hex chars) is set before the gateway starts. Full format, signing setup, and CLI verification live in Audit log.

Doctor page (/doctor)

The Doctor page runs Revka’s built-in diagnostics suite on demand and reports a pass/warn/fail summary plus a result per check, grouped by subsystem category. It mirrors the revka doctor CLI.

Click Run Diagnostics to execute. The page posts an empty body and receives a list of results:

POST /api/doctor
Authorization: Bearer rk_<token>
Content-Type: application/json

{}

{
  "results": [
    { "category": "network",  "message": "Provider reachable",       "severity": "ok" },
    { "category": "memory",   "message": "Kumiho round-trip slow",    "severity": "warn" },
    { "category": "agent",    "message": "MCP server not connected",  "severity": "error" }
  ],
  "summary": { "ok": 8, "warnings": 1, "errors": 1 }
}

Each result carries a category, a human-readable message, and a severity of ok, warn, or error. The summary panel tallies the counts. Checks typically span subsystems such as API-key/provider connectivity, memory backend, MCP connections, network, and filesystem.

Note

Results are not persisted — they reflect the moment you ran them, so re-run after changing config. Use Doctor for one-shot troubleshooting; for continuous liveness use GET /api/health. The same suite is available from the terminal via revka doctor (and revka self-test), documented in revka doctor, status & self-test.

Device pairing page (/pairing)

The Pairing page manages the devices (browsers, phones, sidecars) authorized to call the gateway. Every /api/* request carries a Authorization: Bearer rk_<token> token obtained through pairing; this page is where you mint codes for new devices, show a QR code, rotate the code, and revoke devices you no longer trust.

It uses these endpoints:

Action	Method + path	Auth
List paired devices	GET /api/devices	Bearer
Generate a new pairing code	POST /api/pairing/initiate	Bearer
Revoke a device	DELETE /api/devices/{id}	Bearer
Read the current startup code	GET /pair/code	None

POST /api/pairing/initiate returns a fresh code that a new device exchanges for its own token:

{ "pairing_code": "123456" }

The device list (GET /api/devices) returns a DeviceInfo per entry — id, name, device_type, hardware, paired_at, last_seen, and ip_address — so you can tell paired clients apart and revoke the right one. Revoking with DELETE /api/devices/{id} invalidates that device’s bearer token immediately.

Pair a new device

1. Click Pair New Device to call /api/pairing/initiate and display a 6-digit code and a QR code.
2. On the new device, scan the QR (or type the code manually into the dashboard login screen).
3. The new device posts the code to POST /api/pair with optional device metadata and receives its own persistent token.
4. The new device appears in the list. Revoke any device later with the trash icon.

QR payload format

The QR code encodes a JSON string so a mobile client can auto-fill the host and code:

{ "v": 1, "type": "revka-pair", "host": "<origin><basePath>", "code": "<6-digit>" }

host is the gateway origin plus any reverse-proxy base path, so a scanning client knows exactly where to send POST /api/pair. Rotating the code generates a fresh value immediately and invalidates the previous one.

Note

A 401 from any dashboard request dispatches a revka-unauthorized event and forces re-pairing. On first-run setup, the localhost dashboard auto-fetches the code from GET /pair/code and shows it in a large badge to copy; a remote browser instead reads the 6-digit code from the daemon’s terminal output. The token persists to config, so a daemon restart does not require re-pairing. Pairing security — brute-force lockout, service tokens, token rotation, and require_pairing — is covered in Secrets, pairing & device auth and Pairing & authentication.

Approval toaster & agent events

Two app-wide systems run on every dashboard page, independent of which route you are viewing.

Agent events (global SSE context)

On startup the dashboard opens an application-level SSE subscription to the gateway’s broadcast event stream and shares it with every component:

GET /api/events
Authorization: Bearer rk_<token>
Accept: text/event-stream

Events use a { "type": "...", "payload": { ... }, "timestamp": "..." } envelope and include channel_event, human_approval_request, and observability metrics. This stream is the backbone for real-time updates such as the approval toaster below — components subscribe to the shared context rather than each opening their own connection.

Approval toaster

When a workflow run step enters the approval_required state, the gateway broadcasts a human_approval_request on /api/events. The dashboard’s pending-approvals context collects those and pops a toast with Approve / Reject buttons — on whatever page you happen to be on. Acting on the toast resolves the gate inline:

POST /api/workflows/runs/{run_id}/approve
Authorization: Bearer rk_<token>
Content-Type: application/json

{ "approved": true, "feedback": "looks good" }

Send "approved": false to reject; the optional feedback string is passed back to the run. Because the toaster is cross-page, an approval raised by a background workflow surfaces even if you are on Logs, Doctor, or Skins. A badge count also shows the number of pending approvals. The same approve/reject flow is available from the Workflows, editor & runs page; the gate lifecycle is described in Runs, approvals & checkpoints.

UI Skins page (/skins)

The Skins page browses, activates, uploads, and deletes UI skin packages that re-theme the dashboard. A skin is a ZIP containing a revka-skin.json manifest with CSS-variable token overrides and named image asset slots, defined per light/dark mode. Two built-in skins — revka (the default neutral-graphite enterprise palette) and matrix (the green console look) — are always present and cannot be deleted.

It is backed by these routes:

Action	Method + path	Auth
List installed skins	GET /api/skins	Bearer
Import a skin ZIP	POST /api/skins/import	Bearer
Delete a skin	DELETE /api/skins/{id}	Bearer
Serve a skin asset	GET /api/skins/{id}/assets/{path}	Bearer

GET /api/skins returns skin summaries (id, name, version, builtin, and the parsed manifest); built-in skins carry "builtin": true and treat deletion as a no-op. Each skin card shows light/dark mode previews (a swatch with up to four colour chips). Click Activate to apply a skin; drag-and-drop a ZIP onto the page or use the upload button to install one; delete with the trash icon.

Caution

The active skin and mode are stored in localStorage and re-applied on the next load. v1 skins are intentionally not plugins: they cannot run JavaScript, ship arbitrary CSS, embed HTML, use SVG, or load remote URLs.

Import limits and validation

Import (POST /api/skins/import) takes the raw ZIP body and enforces strict limits:

Limit	Value
ZIP body	25 MiB
Request timeout	120 seconds
Extracted total size	50 MiB
File count	128
Allowed extensions	.json, .png, .jpg, .jpeg, .webp

The importer rejects a package that has a missing or duplicate root revka-skin.json, absolute paths, .. traversal, separators that escape the skin root, symlinks, duplicate entries, unsupported extensions, unknown modes or asset slots, the reserved IDs revka/matrix, an invalid ID, manifest asset references missing from the ZIP, or any JavaScript/CSS/HTML/SVG/remote-URL content. Imported skins are stored under {workspace_dir}/skins/{skin_id}/.

UI skins reference

revka-skin.json manifest

The manifest declares an id, display name, version, schemaVersion (must be 1), and a modes object with light, dark, or both. Each mode may define tokens (CSS-variable overrides), assets (slot → relative path), and an optional preview image.

revka-skin.json        ← manifest at ZIP root
assets/

{
  "schemaVersion": 1,
  "id": "rabbit_garden",
  "name": "Rabbit Garden",
  "version": "1.0.0",
  "modes": {
    "light": {
      "tokens": {
        "--revka-bg-base": "#f7fbf2",
        "--revka-bg-surface": "#ffffff",
        "--revka-text-primary": "#142018",
        "--revka-signal-live": "#4e9f5b",
        "--revka-radius-md": "14px"
      },
      "assets": {
        "brandLogo": "assets/logo.png",
        "operatorAvatar": "assets/avatar.webp",
        "dashboardHero": "assets/hero.jpg"
      },
      "preview": "assets/hero.jpg"
    },
    "dark": {
      "tokens": {
        "--revka-bg-base": "#090607",
        "--revka-text-primary": "#f6ecef"
      }
    }
  }
}

Field	Purpose
schemaVersion	Must be 1
id	Storage ID; lowercase letters, numbers, -, and _ only
name	Display name
version	Skin package version
modes	Object containing light, dark, or both

Token contract

Authored tokens must use the canonical --revka-* namespace. The --pc-* compatibility tokens are generated by the frontend bridge and must not be authored directly. Accepted values are colours (hex, rgb(), rgba(), hsl(), hsla()) and bounded CSS lengths (px, rem, em, %) for radius/spacing/font-size-like tokens. Rejected in v1: url(...), var(...), expression(...), JavaScript-like URLs, shadow tokens, background-image tokens, and arbitrary CSS.

Token	Use
--revka-bg-base	page background
--revka-bg-shell	sidebar / shell surface
--revka-bg-surface	cards and contained surfaces
--revka-bg-panel	translucent panel background
--revka-border-soft / --revka-border-strong	low-emphasis / active borders
--revka-text-primary / --revka-text-secondary / --revka-text-muted	text emphasis levels
--revka-signal-live / --revka-signal-network	primary / secondary accent
--revka-radius-sm / --revka-radius-md / --revka-radius-lg	corner radii

Asset slots

Asset values are relative paths under assets/ (remote URLs, absolute paths, traversal, and SVG are rejected). The full slot set:

Slot	UI use
brandLogo	sidebar / header brand image
operatorAvatar	operator / agent avatar surfaces
dashboardHero	dashboard banner image
dashboardShowcase	large dashboard visual panel (character / scene / product art)
dashboardAccent	small dashboard showcase accent prop or emblem
shellTexture	subtle shell background texture
panelDecoration	subtle panel corner decoration
pageBackdrop	full application backdrop behind the shell
sidebarBackdrop	sidebar background art or texture
headerBackdrop	top header command-band background art
graphBackdrop	workflow / team graph canvas background
metricDecoration	overview metric card decoration
runCardDecoration	selected-run / run-summary decoration
stepCardDecoration	selected-step / selected-node decoration
timelineDecoration	priority timeline decoration
riskRailDecoration	risk rail card decoration
agentRailDecoration	agent rail card decoration
commandBandDecoration	command band card decoration
recentRunsDecoration	recent runs rail decoration
statusRunningBadge	running status badge art
statusSuccessBadge	completed / success status badge art
statusFailedBadge	failed status badge art
statusPendingBadge	pending / blocked status badge art
statusSkippedBadge	skipped status badge art

Note

Per-agent and per-team profile images are not skin slots — they are identity assets uploaded from the Agents and Teams screens (POST /api/agents/avatar, POST /api/teams/avatar) and stored as Kumiho artifacts. See Agents, teams & canvas.

Theme / skin system

Underneath the Skins page is a CSS-variable-based theme runtime exposed through a ThemeContext. It provides a dark/light mode toggle plus skin management to every component:

• resolvedTheme — the effective light/dark mode currently applied.
• toggleMode() — switch between light and dark.
• setSkin(id) — activate an installed skin (built-in or imported).
• deleteSkin(id) — remove an imported skin.
• getSkinAsset(slotName) — resolve a slot (for example brandLogo) to its served URL for the active skin and mode, falling back to the built-in asset when a slot is unset.

Both the active skin and the mode persist in localStorage and are re-applied on the next load, so a branded deployment stays branded across reloads. The built-in light/dark themes always exist independently of any uploaded skin package; uploaded skins layer their token and asset overrides on top.

Language switcher (i18n)

The dashboard is fully internationalised. Every UI string flows through a useT() hook — t(key) for plain strings and tpl(key, vars) for interpolated ones — with the supported locales defined in the i18n module. A language switcher in the layout header changes the active locale at runtime, and the choice is persisted in localStorage so it survives page reloads. Switching locale does not affect agent output or stored data; it only re-renders the dashboard chrome.
